Mileking MK828 LT255/70 R16 108/104S

Description

Mileking MK828 LT255/70 R16 108/104S tire:

1. Core Specifications

• Tire Type: Light Truck (LT) Metric
• Size: 255/70R16
  • Section Width: 255mm (10.04″)
  • Aspect Ratio: 70% (178.5mm sidewall)
  • Rim Width Range: 6.5-8.5″
  • Overall Diameter: 30.1″ (764mm)
  • Revs Per Mile: ~690
  • Static Radius: 14.4″ (366mm)

2. Load & Speed Ratings

• Load Index: 108/104
  • Single: 2,205 lbs (1,000kg)
  • Dual: 1,984 lbs (900kg)
• Speed Rating: S (112mph/180kph)
• Load Range: D (8-ply rated)
• Max Inflation: 65psi (single), 80psi (dual)

3. Structural Engineering

• Carcass: 3-ply polyester (2 sidewall, 1 crown)
• Belting System:
  • 2 high-tensile steel belts
  • 1 nylon reinforcement layer
• Bead: 0.047″ steel wires (2 per side)
• Tread Depth: 13/32″ (10.3mm) new
• Compound: Silica-enhanced all-season

4. Performance Metrics

Load Capacity Analysis:

• Max GVWR (4 tires): 8,820 lbs (4,000kg)
• Loaded Radius: 14.1″ (358mm) @ full load

Dynamic Performance:

• Lateral Acceleration: 0.81g (dry)
• Braking Distance: 128ft (60-0mph, dry)
• Rolling Resistance: 10.2kg/t (EU Label: C)

Durability Indicators:

• Treadwear Index: 420 (UTQG)
• Puncture Resistance: 25% better than LT245

5. Tread Design Features

• Pattern: Asymmetric 4-rib
• Groove Configuration:
  • 4 circumferential channels
  • 18 lateral grooves
  • 3D siping density: 28 sipe/cm²
• Shoulder Design:
  • Stepped block geometry
  • 45° chamfered edges
  • Stone ejector ribs

6. Vehicle Compatibility

Vehicle Class	Recommended Usage
3/4-Ton Pickups	Primary fitment
Full-Size SUVs	Optimal
Heavy-Duty Vans	Recommended
1-Ton SRW	Marginal

7. Comparative Analysis

Vs. P255/70R16:

• 32% higher load capacity
• 40% stronger sidewalls
• 18% heavier (41lbs vs 35lbs)

Vs. LT265/70R16:

• 1.2″ narrower section width
• Same load capacity
• Better snow traction

8. Maintenance Parameters

• Inflation Guidelines:
  • Highway: 50psi (unloaded)
  • Max Load: 65psi
  • Towing: 60psi
• Rotation: Modified X-pattern every 5k miles
• Alignment Specs:
  • Camber: ±0.75°
  • Toe: ±0.10°

9. Regulatory Compliance

• DOT FMVSS 119 certified
• ECE R54 approved
• M+S rated (meets R117.02)

10. Field Test Data

• Wet Braking: 142ft (50-0mph)
• Aquaplaning: 68km/h (1mm water)
• Noise: 73dB (coast-by)
• Snow Traction: 15% better than minimum

11. Commercial Considerations

• Price Positioning: Mid-range LT
• Availability: Global aftermarket
• Warranty: 5-year materials
• Runflat Capability: No

12. Performance Limitations

• Not recommended for:
  • Severe winter conditions
  • Extreme off-road use
  • High-speed (>100mph) operation

This tire configuration offers optimal performance for heavy SUVs and light commercial vehicles requiring enhanced load capacity without sacrificing highway comfort. The 255mm section width provides an ideal balance between traction and rolling resistance for mixed-use applications.
